ADN

FESTO Compact cylinder, double-acting A D N

ISO cylinder to ISO 21287 with fixed or self-adjusting cushioning with high variance
Up to 50% less installation space than comparable standards-based cylinders to ISO 15552

Sensor slots on three sides for flush mounting of proximity switches
Mounting option: Female thread and through-hole
Magnet for contactless position sensing
Integrated cushioning for absorbing residual energy

Series

Code Model
536211ADN-12-5-I-P-A
536212ADN-12-10-I-P-A
536213ADN-12-15-I-P-A
536214ADN-12-20-I-P-A
536215ADN-12-25-I-P-A
536216ADN-12-30-I-P-A
536217ADN-12-40-I-P-A
536204ADN-12-5-A-P-A
536205ADN-12-10-A-P-A
536206ADN-12-15-A-P-A
536207ADN-12-20-A-P-A
536208ADN-12-25-A-P-A
536209ADN-12-30-A-P-A
536210ADN-12-40-A-P-A
536226ADN-16-5-I-P-A
536227ADN-16-10-I-P-A
536228ADN-16-15-I-P-A
536229ADN-16-20-I-P-A
536230ADN-16-25-I-P-A
536231ADN-16-30-I-P-A
536232ADN-16-40-l-P-A
536341ADN-16-50-I-P-A
536242ADN-20-5-I-P-A
536243ADN-20-10-I-P-A
536244ADN-20-15-I-P-A
536245ADN-20-20-I-P-A
536246ADN-20-25-I-P-A
536247ADN-20-30-I-P-A
536248ADN-20-40-I-P-A
536249ADN-20-50-I-P-A
536362ADN-20-60-I-P-A
536259ADN-25-5-I-P-A
536260ADN-25-10-I-P-A
536261ADN-25-15-I-P-A
536262ADN-25-20-I-P-A
Code Model
536263ADN-25-25-I-P-A
536264ADN-25-30-I-P-A
536265ADN-25-40-I-P-A
536266ADN-25-50-I-P-A
536383ADN-25-60-I-P-A
536278ADN-32-5-I-P-A
536279ADN-32-10-I-P-A
536280ADN-32-15-I-P-A
536281ADN-32-20-I-P-A
536282ADN-32-25-I-P-A
536283ADN-32-30-I-P-A
536284ADN-32-40-I-P-A
536285ADN-32-50-I-P-A
536286ADN-32-60-I-P-A
536287ADN-32-80-I-P-A
536299ADN-40-5-I-P-A
536300ADN-40-10-I-P-A
53630JADN-40-15-I-P-A
536302ADN-40-20-I-P-A
536303ADN-40-25-I-P-A
536304ADN-40-30-I-P-A
536305ADN-40-40-I-P-A
536306ADN-40-50-I-P-A
536307ADN-40-60-I-P-A
536308ADN-40-80-I-P-A
536289ADN-40-5-A-P-A
536290ADN-40-10-A-P-A
536291ADN-40-15-A-P-A
536292ADN-40-20-A-P-A
536293ADN-40-25-A-P-A
536294ADN-40-30-A-P-A
536295ADN-40-40-A-P-A
536296ADN-40-50-A-P-A
536297ADN-40-60-A-P-A
536298ADN-40-80-A-P-A
Code Model
536320ADN-50-5-I-P-A
53632JADN-50-10-I-P-A
536322ADN-50-15-I-P-A
536323ADN-50-20-I-P-A
536324ADN-50-25-I-P-A
536325ADN-50-30-I-P-A
536326ADN-50-40-I-P-A
536327ADN-50-50-I-P-A
536328ADN-50-60-I-P-A
536329ADN-50-80-I-P-A
536310ADN-50-5-A-P-A
536311ADN-50-10-A-P-A
536312ADN-50-15-A-P-A
836313ADN-50-20-A-P-A
536314ADN-50-25-A-P-A
536315ADN-50-30-A-P-A
536316ADN-50-40-A-P-A
536317ADN-50-50-A-P-A
536318ADN-50-60-A-P-A
536319ADN-50-80-A-P-A
536342ADN-63-10-I-P-A
536343ADN-63-15-I-P-A
536344ADN-63-20-I-P-A
536345ADN-63-25-I-P-A
536346ADN-63-30-I-P-A
536347ADN-63-40-I-P-A
536348ADN-63-50-I-P-A
536349ADN-63-60-I-P-A
536350ADN-63-80-I-P-A
536363ADN-80-10-I-P-A
536364ADN-80-15-I-P-A
536365ADN-80-20-I-P-A
536366ADN-80-25-I-P-A
536367ADN-80-30-I-P-A
536368ADN-80-40-I-P-A
536369ADN-80-50-I-P-A
536370ADN-80-60-I-P-A
536371ADN-80-80-I-P-A
