Electric cylinders ESBF, with spindle drive
| The electric cylinder ESBF is a mechanical linear drive unit with piston rod. The drive component consists of an electrically actuated spindle that converts the rotary motion of the motor into linear motion of the piston rod. The electric cylinder is based on the ISO 15552 standard. The mechanical interfaces are largely compatible with the standards-based cylinder DSBF. The lead screws have lifetime lubrication and are thus maintenance-free |
With a dynamic feed force of up to 17 kN, the extremely powerful electric cylinder ESBF comes into its own wherever heavy-duty and reliable positioning as well as precision and dynamic response are needed.
Available with ball screw drive (size 32 … 100) or lead screw (size 32 … 50)
Ball screw: with three spindle pitches for selecting the optimal force-speed ratio
Optional: high corrosion protection, degree of protection IP65, food-safe piston rod extension
Axial or parallel motor mounting |
|
