ADNGF

FESTO Compact cylinder, metric ADNGF

Cylinder with standard hole pattern, guide rods and yoke plate with fixed or self-adjusting cushioning

ISO 21287
Piston rod secured against rotation by a guide rod and yoke plate
Plain bearing
Optionally with through piston rod
Higher load capacity thanks to guide rod and yoke plate
For position sensing

Code	Model
554205	ADNGF-12-5-P-A
554206	ADNGF-12-10-P-A
554207	ADNGF-12-15-P-A
554208	ADNGF-12-30-P-A
554210	ADNGF-12-30-P-A
554211	ADNGF-12-40-P-A
554216	ADNGF-16-25-P-A
554217	ADNGF-16-30-P-A
554218	ADNGF-16-t0-P-A
554219	ADNGF-16-50-P-A
554222	ADNGF-20-15-P-A
554223	ADNGF-20-20-P-A
554224	ADNGF-20-25-P-A
554225	ADNGF-20-30-P-A
554229	ADNGF-25-5-P-A
554230	ADNGF-25-10-P-A
554231	ADNGF-25-15-P-A
554233	ADNGF-25-25-P-A
554234	ADNGF-25-30-P-A
554235	ADNGF-25-40-P-A
554236	ADNGF-25-50-P-A

Code	Model
554243	ADNGF-32-30-P-A
574027	ADNGF-32-40-PPS-A
554248	ADNGF-40-5-P-A
554249	ADNGF-40-10-P-A
554250	ADNGF-40-15-P-A
554251	ADNGF-40-20-P-A
554255	ADNGF-40-50-P-A
554256	ADNGF-40-60-P-A
554257	ADNGF-40-80-P-A
574031	ADNGF-40-10-PPS-A
574032	ADNGF-t0-15-PPS-A
574033	ADNGF-40-30-PPS-A
574034	ADNGF-t0-25-PPS-A
574035	ADNGF-40-30-PPS-A
574036	ADNGF-t0-40-PPS-A
574037	ADNGF-40-50-PPS-A
574038	ADNGF-t0-60-PPS-A
574039	ADNGF-40-80-PPS-A
554260	ADNGF-50-15-P-A
554261	ADNGF-50-20-P-A
554262	ADNGF-50-25-P-A

Code	Model
554263	ADNGF-50-30-P-A
554264	ADNGF-50-40-P-A
554265	ADNGF-50-50-P-A
554266	ADNGF-50-60-P-A
554267	ADNGF-50-80-P-A
554268	ADNGF-63-10-P-A
554269	ADNGF-63-15-P-A
554270	ADNGF-63-20-P-A
554272	ADNGF-63-30-P-A
554273	ADNGF-63-40-P-A
554274	ADNGF-63-50-P-A
554275	ADNGF-63-60-P-A
554276	ADNGF-63-80-P-A
554277	ADNGF-80-10-P-A
554278	ADNGF-80-15-P-A
554279	ADNGF-80-20-P-A
554280	ADNGF-80-25-P-A
577230	ADNGF-100-50-PPS-A
577231	ADNGF-100-60-PPS-A
577232	ADNGF-100-80-PPS-A

ADNGF

ADNGF
