D-Series LR

Pressure Regulator LR
Sturdy control valve with or without safety lock against unauthorised adjustment
Lockable design
Two pressure gauge connections for different installation options
Micro, mini, midi size: directly actuated diaphragm regulator
Maxi size: piloted piston regulator, diaphragm regulator LRS-DI
Optional return flow option for exhausting from output 2 to input 1
Available with pressure gauge
Size micro, mini, midi, maxi
Series

Code Model
546436LR-D-MAXI
186457LR-1/2-D-7-MAXI
186455LR-1/2-D-MAXI
162588LR-3/4-D-7-MAXI
159626LR-3/4-D-MAXI
162589LR-1-D-7-MAXI
159627LR-1-D-MAXI
186453LR-1/4-D-7-MIDI
186451LR-1/4-D-MIDI
162585LR-3/8-D-7-MIDI
159580LR-3/8-D-MIDI
162586LR-1/2-D-7-MIDI
159581LR-1/2-D-MIDI
162587LR-3/4-D-7-MIDI
162581LR-3/4-D-MIDI
162582LR-1/8-D-7-MINI
159624LR-1/8-D-MINI
162583LR-1/4-D-7-MINI
159625LR-1/4-D-MINI
162584LR-3/8-D-7-MINI
162580LR-3/8-D-MINI
8002371LR-1/2-D-7-MAXI-MPA
8002370LR-1/2-D-MAXI-MPA
8002294LR-3/4-D-7-MAXI-MPA
8002276LR-3/4-D-MAXI-MPA
8002295LR-1-D-7-MAXI-MPA
8002277LR-1-D-MAXI-MPA
8002369LR-1/4-D-7-MIDI-MPA
8002368LR-1/4-D-MIDI-MPA
Code Model
8002291LR-3/8-D-7-MIDI-MPA
8002256LR-3/8-D-MIDI-MPA
8002292LR-1/2-D-7-MIDI-MPA
8002257LR-1/2-D-MIDI-MPA
8002293LR-3/4-D-7-MIDI-MPA
8002287LR-3/4-D-MIDI-MPA
8002288LR-1/8-D-7-MINI-MPA
8002274LR-1/8-D-MINI-MPA
8002289LR-1/4-D-7-MINI-MPA
8002275LR-1/4-D-MINI-MPA
8002290LR-3/8-D-7-MINI-MPA
8002286LR-3/8-D-MINI-MPA
186458LR-1/2-D-7-O-MAXI
186456LR-1/2-D-O-MAXI
162604LR-3/4-D-7-O-MAXI
162596LR-3/4-D-O-MAXI
162605LR-1-D-7-O-MAXI
162597LR-1-D-O-MAXI
186454LR-1/4-D-7-O-MIDI
186452LR-1/4-D-O-MIDI
162601LR-3/8-D-7-O-MIDI
162593LR-3/8-D-O-MIDI
162602LR-1/2-D-7-O-MIDI
162594LR-1/2-D-O-MIDI
162603LR-3/4-D-7-O-MIDI
162595LR-3/4-D-O-MIDI
162598LR-1/8-D-7-O-MINI
162590LR-1/8-D-O-MINI
162599LR-1/4-D-7-O-MINI
Code Model
162591LR-1/4-D-O-MINI
162600LR-3/8-D-7-O-MINI
162592LR-3/8-D-O-MINI
192311LR-1/4-D-7-I-MIDI
192310LR-1/4-D-I-MIDI
192313LR-3/8-D-7-I-MIDI
192312LR-3/8-D-I-MIDI
192315LR-1/2-D-7-I-MIDI
192314LR-1/2-D-I-MIDI
192317LR-3/4-D-7-I-MIDI
192316LR-3/4-D-I-MIDI
192299LR-1/8-D-7-I-MINI
192298LR-1/8-D-I-MINI
192301LR-1/4-D-7-I-MINI
192300LR-1/4-D-I-MINI
192303LR-3/8-D-7-I-MINI
192302LR-3/8-D-I-MINI
8002394LR-1/4-D-I-MIDI-MPA
8002395LR-3/8-D-7-I-MIDI-MPA
8002396LR-1/2-D-I-MIDI-MPA
8002397LR-3/4-D-I-MIDI-MPA
8002389LR-1/8-D-7-I-MINI-MPA
8002388LR-1/8-D-I-MINI-MPA
8002391LR-1/4-D-7-I-MINI-MPA
8002390LR-1/4-D-I-MINI-MPA
8002393LR-3/8-D-7-I-MINI-MPA
8002392LR-3/8-D-I-MINI-MPA
192319LR-1/4-D-7-O-I-MIDI
192318LR-1/4-D-O-I-MIDI
192321LR-3/8-D-7-O-I-MIDI
