DFM

FESTO Guided drive, metric DFM

With the guided drive DFM, you can count on precise guidance and great absorption of torques and lateral forces, coupled with a sturdy, compact design. It is suitable for clamping, lifting and stopping applications.

Drive and guide unit in a single housing

High resistance to torques and lateral forces

Plain or recirculating ball bearing guide

Wide variety of mounting and attachment options

Wide range of variants for customised applications

Variants recommended for production systems for manufacturing lithium-ion batteries

CLAMPING : The guided drive is perfectly suited to clamping components for reliable further processing.

LIFTING : The guided drive effortlessly transports and lifts loads of over 200 kg, powerfully and dynamically.

STOPPING : Loads of up to 150 kg are stopped reliably and safely, making the guided drive a resilient and sturdy stopper cylinder

Code	Model
4149944	DFM-6-5-P-A-GF
4149945	DFM-6-10-P-A-GF
4149946	DFM-6-15-P-A-GF
4149947	DFM-6-20-P-A-GF
170824	DFM-12-10-P-A-GF
170825	DFM-12-20-P-A-GF
170826	DFM-12-25-P-A-GF
170827	DFM-12-30-P-A-GF
170828	DFM-12-40-P-A-GF
170829	DFM-12-50-P-A-GF
170830	DFM-12-80-P-A-GF
170831	DFM-12-100-P-A-GF
170832	DFM-16-10-P-A-GF
170833	DFM-16-20-P-A-GF
170834	DFM-16-25-P-A-GF
170835	DFM-16-30-P-A-GF
170836	DFM-16-40-P-A-GF
170837	DFM-16-50-P-A-GF
170838	DFM-16-80-P-A-GF
170839	DFM-16-100-P-A-GF
170847	DFM-25-20-P-A-GF
170848	DFM-25-25-P-A-GF
170849	DFM-25-30-P-A-GF
170851	DFM-25-50-P-A-GF
170852	DFM-25-80-P-A-GF
170853	DFM-25-100-P-A-GF
170854	DFM-32-20-P-A-GF

Code	Model
170855	DFM-32-25-P-A-GF
170856	DFM-32-30-P-A-GF
170857	DFM-32-40-P-A-GF
170859	DFM-32-80-P-A-GF
170860	DFM-32-100-P-A-GF
170861	DFM-32-125-P-A-GF
170862	DFM-32-160-P-A-GF
170863	DFM-32-200-P-A-GF
170872	DFM-50-50-P-A-GF
170873	DFM-50-80-P-A-GF
170874	DFM-50-100-P-A-GF
170875	DFM-50-125-P-A-GF
170876	DFM-50-160-P-A-GF
170877	DFM-50-200-P-A-GF
170878	DFM-63-25-P-A-GF
170879	DFM-63-50-P-A-GF
170880	DFM-63-80-P-A-GF
170881	DFM-63-J00-P-A-GF
170882	DFM-63-125-P-A-GF
170883	DFM-63-J60-P-A-GF
170884	DFM-63-200-P-A-GF
170885	DFM-80-25-P-A-GF
170886	DFM-80-50-P-A-GF
170887	DFM-80-80-P-A-GF
170888	DFM-80-100-P-A-GF
170889	DFM-80-J 25-P-A-GF
170890	DFM-80-160-P-A-GF

Code	Model
170891	DFM-80-200-P-A-GF
170892	DFM-100-2S-P-A-GF
170893	DFM-100-50-P-A-GF
170894	DFM-100-80-P-A-GF
170895	DFM-100-100-P-A-GF
170896	DFM-100-125-P-A-GF
170897	DFM-100-160-P-A-GF
170898	DFM-100-200-P-A-GF
170922	DFM-25-20-P-A-KF
170946	DFM-50-25-P-A-KF
170947	DFM-50-50-P-A-KF
170948	DFM-50-80-P-A-KF
170954	DFM-63-50-P-A-KF
170960	DFM-80-25-P-A-KF
170961	DFM-80-50-P-A-KF
170962	DFM-80-80-P-A-KF
170963	DFM-80-100-P-A-KF
170964	DFM-80-125-P-A-KF
170965	DFM-80-160-P-A-KF
170966	DFM-80-200-P-A-KF
170967	DFM-100-25-P-A-KF
170968	DFM-100-50-P-A-KF
170969	DFM-100-80-P-A-KF
170970	DFM-100-100-P-A-KF
170971	DFM-100-125-P-A-KF
170972	DFM-100-160-P-A-KF
170973	DFM-100-200-P-A-KF

DFM

DFM
