| FESTO Radial gripper DHRS |
| The cost-effective standard gripper with higher gripping forces of up to 725 Nm effortlessly masters most gripping applications. It comes in different sizes, offers position sensing, optional gripping force backup and high torque loads. |
Lateral gripper jaw support for high torque loads
Self-centring
Internal fixed flow control
Max. repetition accuracy
Slotted guide
Can be used as a double- and single-acting gripper
Single-acting variant or with gripping force backup, normally closed (NC)
Wide range of adaptation options on the drives |
