DSM

FESTO Semi-rotary drive DSM

Double-acting semi-rotary vane drive and metal fixed stops. The swivel angle is infinitely adjustable across the entire swivel range.

Double-acting semi-rotary drive with vane
The swivel angle is infinitely adjustable over the entire swivel range
High precision thanks to metal fixed stops
Polyurethane ensures a long service life for the rotary vane and sealing system
Easy precision adjustment of the end positions using the cushioning components

Code	Model
547591	DSM-12-270-A-B
547592	DSM-16-270-A-B
547593	DSM-25-270-A-B
547594	DSM-32-270-A-B
547595	DSM-40-270-A-B
552083	DSM-63-270-A-B
547570	DSM-12-270-P-A-B
547574	DSM-16-270-P-A-B
547578	DSM-25-270-P-A-B
547582	DSM-32-270-P-A-B
547586	DSM-40-270-P-A-B
552079	D5M-63-270-P-A-B
566203	DSM-12-270-PI-A-B
566205	DSM-16-270-P1-A-B
566207	DSM-25-270-PI-A-B
566209	DSM-32-270-PI-A-B
566211	DSM-40-270-PI-A-B
566213	DSM-63-270-PI-A-B
547572	DSM-12-270-CC-A-B
547576	DSM-16-270-CC-A-B
547580	DSM-25-270-CC-A-B

Code	Model
547584	DSM-32-270-CC-A-B
547588	DSM-40-270-CC-A-B
552081	DSM-63-270-CC-A-B
547596	DSM-12-270-M-A-B
547597	DSM-16-270-M-A-B
547598	DSM-25-270-M-A-B
547599	DSM-32-270-M-A-B
547600	D5M-40-270-M-A-B
552084	DSM-63-270-M-A-B
547575	DSM-16-270-P-M-A-B
547579	DSM-25-270-P-M-A-B
547583	DSM-32-270-P-M-A-B
566204	DSM-12-270-PI-FW-A-B
566206	DSM-16-270-PI-FW-A-B
566208	DSM-25-270-PI-FW-A-B
566210	DSM-32-270-PI-FW-A-B
566212	DSM-40-270-P1-M-A-B
566214	DSM-63-270-PI-FW-A-B
547573	DSM-12-270-CC-M-A-B
547577	DSM-16-270-CC-M-A-B
547581	DSM-25-270-CC-M-A-B

Code	Model
547i85	DSM-32-270-CC-M-A-B
547589	DSM-40-270-CC-M-A-B
552082	DSM-63-270-CC-M-A-B
1145122	DSM-T-12-270-A-B
1145123	DSM-T16-270-A-B
1145126	DSM-T40-270-A-B
1145086	DSM-T12-270-P-A-B
1145106	DSM-T32-270-CC-A-B
1145130	DSM-T25-270-M-A-B
1145131	DSM-T32-270-M-A-B
1145132	DSM-T40-270-M-A-B
1145133	DSM-T63-270-M-A-B
1145087	DSM-T12-270-P-M-A-B
1145093	DSM-T16-270-P-M-A-B
1145099	DSM-T25-270-P-M-A-B
1145113	DSM-T40-270-CC-FW-A-B
1145119	DSM-T63-270-CC-M-A-B
13691J3	DSM-32-270-HD-A-B
1369114	DSM-40-270-HD-A-B
1369115	DSM-63-270-HD-A-B
1369116	DSM-12-270-P1-HD-A-B
1369117	DSM-16-270-PI-HD-A-B
1369125	DSM-32-270-CC-HD-A-B
