LRP

Precision pressure regulator LRP
For sensitive applications that require a pressure hysteresis of 0.02 bar. The output pressure p2 is adjustable within the pressure regulation range

Lockable design
Good control characteristics with minimal pressure hysteresis and primary pressure compensation
High secondary exhausting
Variants to EU Explosion Protection Directive (ATEX)
Series

Code Model
2416371LRP-1/8-6
2418761LRP-7.0-6
159500LRP-1/4-0,7
549918LRP-1/4-0,7-EX4
194690LRPS-1/4-0,7
8196140LRP-1/4-0.7-F1A
162834LRP-1/4-2,5
549919LRP-1/4-2,5-EX4
Code Model
194691LRPS-1/4-2,5
8196141LRP-1/4-2.5-F1A
159501LRP-1/4-4
549920LRP-1/4-4-EX4
194692LRPS-1/4-4
159502LRP-1/4-10
549921LRP-1/4-10-EX4
194693LRPS-1/4-10
8196142LRP-1/4-10-F1A
