On/off valve MS-EM1
All compressed air preparation functions: pressure control, switch-on, filter control and soft start valves with safety function, filter, pressure and flow sensors, dryers, water separators, sensors, lubricators and distributors.
Manual 3/2-way valve for pressurising and exhausting pneumatic systems
A silencer can be attached or the exhaust air ducted at port 3
Switching position is immediately recognisable
Optionally with pressure gauge and pressure sensor
Series

Code Model
541262MS4-EM1-1/8
541258MS4-EM1-1/4
541261MS4-EM1-1/4-Z
8183561MS4-EM1-1/4-F1A1)
541271MS6-EM1-1/4
541275MS6-EM1-3/8
541267MS6-EM1-1/2
541270MS6-EM1-1/2-Z
8183562MS6-EM1-1/2-F1A1)
Code Model
541263MS4-EM1-1/8-S
541259MS4-EM1-1/4-S
541260MS4-EM1-1/4-S-Z
541272MS6-EM1-1/4-S
541276MS6-EM1-3/8-S
541268MS6-EM1-1/2-S
541269MS6-EM1-1/2-S-Z
8232833MS4-EM1-AGC
8232875MS6-EM1-AGE
