MSB - FRC

Service unit combination MSB4 , MSB6 , MSB9
With the pre-configured MS series, Festo offers a holistic concept for your compressed air preparation. For simple standard applications as well as for application-specific solutions with the highest quality requirements
Filter, regulator and lubricator functions in a single unit
High flow rate and highly efficient in removing contaminants
Good control characteristics with minimal pressure hysteresis
Series

Code Model
531133MSB4-1/8-FRC5:J1M1
531119MSB4-1/4-FRC6:J2M1
531121MSB4-1/4-FRC7:J3M1
531109MSB4-1/4-FRC1:J5M1
8042669MSB4-1/4-FRC13:J120M1
531117MSB4-1/4-FRC5:J1M1
531118MSB4-1/4-FRC5:J1M1-Z
530268MSB6-1/4-FRC5:J1M1
530292MSB6-3/8-FRC5:J1M1
530236MSB6-1/2-FRC12:J10M2
Code Model
530232MSB6-1/2-FRC10:J12M2
530246MSB6-1/2-FRC6:J2M1
530248MSB6-1/2-FRC7:J3M1
530234MSB6-1/2-FRC11:J9M2
530230MSB6-1/2-FRC1:J5M1
8042673MSB6-1/2-FRC13:J120M1
530252MSB6-1/2-FRC9:J11M2
530244MSB6-1/2-FRC5:J1M1
530245MSB6-1/2-FRC5:J1M1-Z
