PUN-S

Spiral plastic tubing PUN-S

The single or dual tubing PUN-S/PUN-S-DUO with straight outlets is flexible in use, extremely elastic and has an unbeatable reset force for motion sequences in machines. The pre-assembled solution PUN-SG has rotatable threaded outlets for the supply of compressed air tools.

Polyurethane
Also available as DUO plastic tubing
Operating medium: compressed air, vacuum
High resistance to UV radiation and stress cracks

Code	Model
197587	PUN-4X0,75-S-0,5-BL
197588	PUN-4X0,75-S-1-BL
197589	PUN-4X0,75-S-1,5-BL
197590	PUN-6X1-S-1-BL
197591	PUN-6X1-S-2-BL
197592	PUN-6X1-S-6-BL
197593	PUN-8X1,25-S-1-BL
197594	PUN-8X1,25-S-2-BL
197595	PUN-8X1,25-S-6-BL
197596	PUN-10X1,5-S-1-BL
197597	PUN-10X1,5-S-2-BL
197598	PUN-10X1,5-S-6-BL
197599	PUN-12X2-S-1-BL
197600	PUN-12X2-S-2-BL
197601	PUN-12X2-S-6-BL

Code	Model
197602	PUN-4X0,75-S-0,5-SW
197603	PUN-4X0,75-S-1-SW
197604	PUN-4X0,75-S-1,5-SW
197605	PUN-6X1-S-1-SW
197606	PUN-6X1-S-2-SW
197607	PUN-6X1-S-6-SW
197608	PUN-8X1,25-S-1-SW
197609	PUN-8X1,25-S-2-SW
197610	PUN-8X1,25-S-6-SW
197611	PUN-10X1,5-S-1-SW
197612	PUN-10X1,5-S-2-SW
197613	PUN-10X1,5-S-6-SW
197614	PUN-12X2-S-1-SW
197615	PUN-12X2-S-2-SW
197616	PUN-12X2-S-6-SW

Code	Model
197617	PUN-4X0,75-S-0,5-DUO-BS
197618	PUN-4X0,75-S-1-DUO-BS
197619	PUN-4X0,75-S-1,5-DUO-BS
197620	PUN-6X1-S-1-DUO-BS
197621	PUN-6X1-S-2-DUO-BS
197622	PUN-6X1-S-6-DUO-BS
197623	PUN-8X1,25-S-1-DUO-BS
197624	PUN-8X1,25-S-2-DUO-BS
197625	PUN-8X1,25-S-6-DUO-BS
197626	PUN-10X1,5-S-1-DUO-BS
197627	PUN-10X1,5-S-2-DUO-BS
197628	PUN-10X1,5-S-6-DUO-BS
197629	PUN-12X2-S-1-DUO-BS
197630	PUN-12X2-S-2-DUO-BS
