SDE

Pressure sensor SDE5

Optimally priced and in a modular system, the pressure and vacuum switch SDE5 is the low-cost alternative for simple and fast pressure control. It offers impressive compressed air, control points and vacuum detection as well as object detection via back pressure

Programmable and configurable pressure switch for simple pressure sensing tasks
Threshold/window comparator
Switching point adjustment via teach-in function
Integrated microprocessor
Switching status indicated by an LED visible from all sides
Certification: c UL us listed (OL), C-Tick

Code	Model
527460	SDE5-V1-O-Q4E-P-M8
527457	SDE5-V1-O-Q4-P-M8
567464	SDE5-V1-NF-Q6-V-M8
527458	SDE5-V1-O-Q6-P-M8
542886	SDE5-V1-O1-Q6-P-M8
542887	SDE5-V1-FP-Q6-P-M8
567463	SDE5-V1-NF-Q6E-V-M8
527461	SDE5-V1-O-Q6E-P-M8
542900	SDE5-D10-FP-Q4E-P-M8
527466	SDE5-D10-O-Q4E-P-M8
542889	SDE5-D10-C-Q4E-P-M8
527463	SDE5-D10-O-Q4-P-M8

Code	Model
542891	SDE5-D10-O2-Q6E-P-M8
567465	SDE5-D10-NF-Q6E-V-M8
542892	SDE5-D10-O2-Q6-P-M8
542898	SDE5-D10-FP-Q6-P-M8
567462	SDE5-D10Z-O-Q6-P-M8
542894	SDE5-D10-C-Q6E-P-M8
542897	SDE5-D10-FP-Q6E-P-M8
567466	SDE5-D10-NF-Q6-V-M8
527464	SDE5-D10-O-Q6-P-M8
527467	SDE5-D10-O-Q6E-P-M8
567473	SDE5-D10-O-Q6-N-M8
567460	SDE5-D10Z-FP-Q6-P-M8

Code	Model
567468	SDE5-D10-O-T14E-P-M8
567467	SDE5-D10-FP-T14E-P-M8
567470	SDE5-V1-NF-Q6E-V-K
542888	SDE5-D2-O-Q6E-P-K
542901	SDE5-D10-FP-Q4E-P-K
567469	SDE5-D10-O-Q6-N-K
542895	SDE5-D10-C-Q6E-P-K
567471	SDE5-D10-NF-Q6E-V-K
567472	SDE5-D10-NF-Q6-V-K
542896	SDE5-D10-C3-Q6E-P-K
542899	SDE5-D10-FP-Q6-P-K
542890	SDE5-D10-O-Q6E-P-K
542893	SDE5-D10-O3-Q6E-P-K
